Product Details:
|
| Use: | Trailer Parts | Max Payload: | 1250-2000 Kg |
|---|---|---|---|
| Size: | 40 Mm Square Tube | Material: | Iron |
| Quality: | 100% Guaranteed | Length: | Customer Model |
| Tube: | 40 Mm | Brake: | Hydraulic Brake |
| High Light: | Solid Tube Trailer Straight Axle,40MM Square Trailer Straight Axle,2000Kg Trailer Axle With Brake |
||
How do hydraulic brakes work on a trailer?
When you step on the brake in your tow vehicle and slow down, the trailer pushes against the hitch and presses a hydraulic cylinder. The more you slow down the vehicle, the more pressure on the trailer brakes.
| 5* 4.5", 6*5.5" wheel pattern | |||||
| NO. | Description | QTY | option 1 | option 2 | option 3 |
| 1 | axle shaft | 1 | 45mm round/square | 50mm round/square | |
| 2 | stub axle | 2 | AC00500201 | ||
| 3 | mounting plate | 2 | AT01200107 | ||
| 4 | 10" brake plate | 2 | AZ013L/R | AZ026UR | AT01200103 |
| 5 | nut | 8 | AC00100501 | ||
| 6 | washer | 8 | AC00100502/3 | ||
| 7 | oil seal | 2 | AC00500201 | ||
| 8 | inner bearing | 2 | L68149/10 | L68149/11 | |
| 9 | 10" hub drum | 2 | AC00500300 | AC00300300 | |
| 10 | outer bearing | 2 | LM12749/10 | L68149/10 | |
| 11 | flat washer | 2 | AC00500402 | AC00201001 | |
| 12 | castle nut | 2 | AC00500403 | AC00200701 | |
| 13 | split pin | 2 | AC00500404 | AC00200404 | |
| 14 | dust cap | 2 | AC00500405 | AC00300601 | |
| 15 | drop plate | 2 | AC00300103 | ||
| 16 | wheel nut | 10,12 | 1/2H-10UNF | 7/16"-20UNF | |
FAQ:
1: Could you please make us an offer as soon as possible?
In order to get the price quickly and accurately, please provide the technical drawing or OE number, we will be very grateful.
2: How can you guarantee the quality of your products?
Our products have passed ISO9001 international quality standard certification. Our company has a very strict quality control system.
3: How to solve the problems in the later stage?
We are confident in our products. We pack them well to make sure they are well protected.
As for the transportation of products, our company supports various sea, land and air international transportation. Please confirm the specific transportation plan during the negotiation.
